DT Series FGD Pump

The pump is specially designed for the desulfurization system of the power plant.

Suitable for limestone, gypsum wet desulfurization, for conveying limestone or gypsum slurry

Model：：DT Desulfurization Pump
Discharge Size：：25~900 mm
Suction Size：：40~1200 mm
Flow Rate：：4.4~14000 m³/h
Head：：3.3~147 m
Max. Eff η(%)：：38~88 (%)
Impeller Diameter：：15~110 mm
Max Particle Size：：5~152 mm

Categories: FGD Slurry Pump, Metal Liner Slury Pumps

Inquiry

OEM/ODM Customization

Shi Meng

Contact the account manager for detailed quotes and services

+86 18931183432

sales@hongstonepump.com

We are now offering one-stop deep ODM/OEM cooperation to global brand and channel partners

Get to know more

Description

Design Philosophy

DT series FGD(desulfurization) pump is a cantilever horizontal centrifugal pump with axial suction, single-stage single-suction, and single pump casing structure.

Transmission form: DCZ direct drive,
Shaft seal form: mechanical seal.
Installation and application: The pump outlet is directed vertically upwards.

Product Information

FGD Slurry Pump.pdf

Attributes

Model：：DT Desulfurization Pump
Discharge Size：：25~900 mm
Suction Size：：40~1200 mm
Flow Rate：：4.4~14000 m³/h
Head：：3.3~147 m
Max. Eff η(%)：：38~88 (%)
Impeller Diameter：：15~110 mm
Max Particle Size：：5~152 mm
Speed：：300~2950r/min
Max. Power：：4-1600 (kw)
NPSH：：1.5~6.5m
Weight：：89~11800 (kg)

Suitable for limestone, gypsum wet desulfurization, for conveying limestone or gypsum slurry

Structure

Technical Mastery
Suitable for limestone, gypsum wet desulfurization, for conveying limestone or gypsum slurry. The chloride ion content of the slurry allowed to be transported is up to 20000ppm, the pH value is between 4.5 and 12, the slurry temperature is ≤65°C, and the slurry weight concentration Cw is up to 60%.

The pump is specially designed for the desulfurization system of the power plant. Mainly used in the desulfurization main circulation system and peripheral circulation system of thermal power plants. It can also be used to transport limestone or gypsum slurries in desulfurization systems in industries such as aluminum and oil refining.

Material of overcurrent parts: The overcurrent parts are made of special materials GLH-5 and GLH-6 specially used for desulfurization conditions.
